Automated climate control with two fans - for 35m³

Temporarily out of stock Articles combined in set
Automated climate control with two fans - for 35m³
Automated climate control with two fans - for 35m³ #0 Automated climate control with two fans - for 35m³ #1 Automated climate control with two fans - for 35m³ #2 Automated climate control with two fans - for 35m³ #3 Automated climate control with two fans - for 35m³ #4 Automated climate control with two fans - for 35m³ #5 Automated climate control with two fans - for 35m³ #6 Automated climate control with two fans - for 35m³ #7 Automated climate control with two fans - for 35m³ #8 Automated climate control with two fans - for 35m³ #9 Automated climate control with two fans - for 35m³ #10 Automated climate control with two fans - for 35m³ #11 Automated climate control with two fans - for 35m³ #12 Automated climate control with two fans - for 35m³ #13
Info
Price
Unit price
431.95 € *
apx. £387.07
EUR
incl. 19% VAT plus shipping"
Shipping
from 7 €
Details
Availability
NOT AVAILABLE
Item number
06833
Group:
Vorteilsset Grow
Tags

Description

Automated (regulated by temperature) ventilation kit. Two fans (for intake and exhaust) are controlled simultaneously to remove used-up and overheated air and provide fresh air.


This assembly set (DIY) is best suited for grow rooms or grow tents with up to 35 m³ of volume.

Assembly instructions:
  1. First you need two holes in the greenhouse walls for the flanges (many grow tens already got holes). Normally the hole for intake is on the cooler side (shaded/sun-protected), extake should be planned on the side where the consumed air (and the noises originating from the outlet) annoy least.
  2. Insert flanges (from outside) and fix them.
  3. Determine the proper length for your air tubes (you should plan the whole construction with exact measurements on paper before starting) and cut them to the right length, then push them through the flanges (from inside) and connect flange and tube.
  4. Connect the first fan with the power cable.
  5. Affix easy rolls on roof or suspension. Connect the fan with the Easy Rolls (the fan has screws for fastening, you have to loosen on and insert the line of the easy roll, the screw it fast again).
  6. Connect hose and fan (use the hose clamp).
  7. Same with the second fan.
  8. Install the SMSCom TwinController on a secure and accessibly place.
  9. Plug in the fans into the Controller's outlest by observing the TwinController Instructions.
  10. Plug-In the TwinController
  11. DONE

Please observe: This installations requires quite some skills, especially the electrical parts of the work should be done by professionals. Please observe the necessary safety precautions. Be sure that your power network and fuses comply with the devices.

Scope of delivery:
  • 1 x SMSCom TwinController
  • 1 x LTI Fan 250mm: 1020 m³/h
  • 1 x LTI Lüfter 315mm: 1300 m³/h
  • 2 x PVC Power Cord
  • 2 x Easy-Rolls for suspension
  • 2m Combi duct hose, 254 mm
  • 2m aluminium duct hose, 315 mm
  • 4 x duct hose clamp
  • 1 x wall flange, 250 mm
  • 1 x wall flange, 315 mm
Set content
Sum of single units:
450.69 €
Saving:
4.00%
Easy Rolls - Double Pack
Hot stuff
1Easy Rolls - Double Pack
6.95 € *
5.0 of 5 stars 9
PVC Net Cord, 1,5 m, 3 x 1.5mm²
Bestseller
1PVC Net Cord, 1,5 m, 3 x 1.5mm²
4.95 € *
Can-Fan (Ruck) Metal in Line Fan RS250 250mm - 890m³/h
Choice available
1Can-Fan (Ruck) Metal in Line Fan RS250 250mm - 890m³/h
99.95 € *
Combi duct hose 254mm
4Combi duct hose 254mm
6.79 € *
Wall Flange  Metal  250mm
2Wall Flange Metal 250mm
4.49 € *
Duct Hose Clamp
4Duct Hose Clamp
1.95 € *
PK Blue Line duct fan 1200m³/ h
Temporarily out of stock
1PK Blue Line duct fan 1200m³/ h
169.95 € *
SMSCOM Twin Controller MK2 7A
Temporarily out of stock
1SMSCOM Twin Controller MK2 7A
124.95 € *
