CarbonActive HomeLine Standard 800Z Activated Carbon Filter 800m³ - 200mm
Info
Price
Unit price
184.83 € *
apx. $199.63
Shipping
from 7 €
Availability
in stock- Variations
-
1000ZL - 1000m³/h - 200mm
235.25 € *apx. $254.09{"list_position":0,"systype":"article","name":"1000ZL - 1000m³/h - 200mm","id":"10638","list_name":"articlelist"}
800Z - 800m³/h - 200mm
184.83 € *apx. $199.63{"list_position":1,"systype":"article","name":"800Z - 800m³/h - 200mm","id":"10637","list_name":"articlelist"}
650Z - 650m³/h - 200mm
142.82 € *apx. $154.26{"list_position":2,"systype":"article","name":"650Z - 650m³/h - 200mm","id":"10636","list_name":"articlelist"}
500ZL - 500m³/h - 125mm
83.99 € *apx. $90.72{"list_position":3,"systype":"article","name":"500ZL - 500m³/h - 125mm","id":"10634","list_name":"articlelist"}
400Z - 400m³/h - 125mm
67.18 € *apx. $72.56{"list_position":4,"systype":"article","name":"400Z - 400m³/h - 125mm","id":"10633","list_name":"articlelist"}
300Z - 300m³/h - 125mm
58.78 € *apx. $63.49{"list_position":5,"systype":"article","name":"300Z - 300m³/h - 125mm","id":"10632","list_name":"articlelist"}
500ZW - 500m³/h - 200mm
117.61 € *apx. $127.03Temporarily out of stock{"list_position":6,"systype":"article","name":"500ZW - 500m³/h - 200mm","id":"10635","list_name":"articlelist"}
200Z - 200m³/h - 125mm
54.58 € *apx. $58.95Temporarily out of stock{"list_position":7,"systype":"article","name":"200Z - 200m³/h - 125mm","id":"10631","list_name":"articlelist"}
The new generation of the ActiveCarbon Homeline Standard filter offers some significant changes. For example, the flange was revised and equipped with an integrated suspension.
Also, it is now possible by means of reducers to adjust the size of the flange to the exhaust system used.
The Filter
The Swiss Activated Carbon Filter neutralizes odors, absorbing 100% of odors.
The new technology allows an adsorption of up to 3,000m³ air per hour with a new weight of 16kg.
The Swiss ACF is an alternative for the standard metal cylinder and has some great advantages:
- * longer durability
- * neutralizes odors 100%
- * minimal pressure loss
- * no pulverized carbon in the air
- * easy installation
- * delivery by mail
- * easy to dispose
- * special pre-filter
The Pre-Filter
The larger substances in the air get trapped in the coarse particulate air filter so the fine particulate air filter won't get clogged. The latter holds back substances larger than 0.4µm (0.0004mm).
This pre-filter substantially prolongs the lifetime of the SwissACF since particles bigger than 0.4µm would damage the pore openings.
Never operate the filter without pre-filter. This would heavily impair the quality and durability.
The pre-filter has a special hook and loop fastener so there's no need to dismantle the SwissACF for a pre-filter change.
Technical Data CarbonActive HomeLine Standard 800Z - Activated Carbon Filter
Weight - only 3.5 kg
Performance - 200m³/h to 800m³/h, best performance at 640m³/h
Pressure loss - 55Pa at 800m³/h, 31Pa at 640m³/h
Diameter 275mm - Height 420m
Connection - 200mm
Details
- Item number
- 10637
- Brand
- CarbonActive
- Maximum flow rate:
- 800 m³/h
- Optimum flow rate:
- 640 m³/h
- Diameter:
- 27,5 cm
- Flange diameter:
- 200 mm
- Height:
- 47,5 cm
- Price:
- 219.95 €
- Material:
- Activated carbon3,00 Synthetics3,00
- Colour:
- Blue3,00 White3,00
