The G-Systems mde controller is a temperature dependant speed controller for rooms with air flow in and out. The fan controller keeps the room temperature constant and under pressure to prevent odour from excaping. It is simple to use, the necessary temperature and the low pressure can be adjusted by two buttons. The fan controller can be operated also with an exhaust only, if air is sucked in on a natural way. The fan controller is supplied as a unit and is ready to use. This reliable fan controller comes in a waterproof casing and socker outlets with lid, perfect for damp locations. Instruction: Plug the exhaust air fan into the left plug signed with FAN1 and the supplier air fan into the right plug signed with FAN2. Install the temperature probe which comes on a 4m long cable to a place where you want to measure the temperature. Be careful not to place the probe close to a hot or light source to obtain a precise measure. Should the temperature cable be too short, it can be elongated up to 50 metres. Pay attention to first disconnect the power cable. Wrong connections or a short circuit destroys sensitive processor parts! Now plug the power cagble into a common 10A or 13A socket. The exhaust FAN1 should now run at 20% to obtain an low-pressure. Adjust the temperature with the upper knob. Should the emasured temperature exceed your set temperature by +2° the ventilator runs at its maximum capacity. The second knob you adjust the low pressure % speed reduce of the supply FAN2 to run between 100% and 50% behind FAN1. FAN2 automatically switches off below the minimum speed of 20% to prevent fan noise and keep the room under pressure. This digital fan controller is perfectly suitable for e.g. a Homebox. Size and Technical Data:
